Compressor air К-150 block
Compressor air К-150 block
| # | type | К-150 block |
| 1 | working environment | air / nitrogen |
| 2 | performance, m3/min | 148 |
| 3 | initial pressure kgf/cm2 | 1 |
| 4 | final pressure kgf/cm2 | 7 |
| 5 | number of revolutions | 13800 |
| 5 | type of motor | СТД-1000 4АЗМ-1000 |
| 6 | motor power | 1000 |
| 7 | kV voltage | 6/10 |
| 8 | number of revolutions | 3000 |
| 9 | number of rotors | 2 |
| 10 | Power consumption, kW | 970 |
| 11 | number in / coolers | 3 |
| 12 | total water consumption | 140 |
| 13 | tº gas terminal in the air / cooling.. | 35-40 |
| 14 | tº the cooling water | 20 |
| 15 | mass of unit kg | 24000 |
| 16 | weight the most. part of the unit, kg | 5000 |
Here you can order a Compressor air К-150 block. To buy a Compressor air К-150 block, contact the sales department Energomash. Sale of a Compressor air К-150 block is carried out to Ukraine, Latvia, Lithuania, Estonia, Bulgaria, Armenia, Uzbekistan, Kazakhstan, Turkmenistan, India, Mongolia, other countries in Europe and Central Asia.
